Frame and Fork
- Frame: Clean X3 26", made of 6061-T6 + 7075-T6 aluminum alloy, with 4-bolt rim brake mount.
- Fork: Clean X2 26", made of 7005-T6 aluminum alloy, with tapered design 1 1/8" - 1.5", with bracket for Post Mount disc brake or 4 bolt rim brake.
Wheels
- Front hub: Clean X2, 28 spokes, without disc mounts, 100 mm wide, black anodized
- Rear hub: Clean X3, with 12 mm thru axle, 32 spokes, no disc mountings, 120 mm wide, black anodized
- Chain tensioner: Clean X2 Integrated tensioner, with two 10-tooth plastic wheels.
- Front rim: Clean 26", with lightened single-ply design, 34 mm width, 28 spoke holes, black anodized finish.
- Rear rim: Clean 26'', with lightened mono-layer design, 48 mm width, 32 spoke holes, black anodized finish
- Spokes: 1.8mm spokes, black color
- Rim tape: Clean
- Front tube: Clean 26
- Rear tube: Clean 26
- Front Tire: Clean Koala 26 "x2.00"
- Rear Tire: Clean Koala 26 "x2.50"
Brakes
- Front brake:Â Trialtech Sport HP, silver.
- Rear brake:Â Trialtech Sport HP, silver.
- Rim brake pads: Magura, black
- Rim brake mounts: Clean X2 Washerless
Drivetrain
- Crankset + bottom bracket: Clean X2 3-piece kit, 30mm diameter, Press-Fit BB30 type, new adjustment system. Crankset length 170 mm, for Shimano HG type cassette sprocket.
- Freewheel: Clean X2 135.9 18T, with 135 engagement points, 9 triggers and 18 teeth, in red color.
- Chain: KMC Z1eHX, silver
- Fixed sprocket: Clean 15T, cassette type Shimano HG
- Pedals: Clean Mono-cage, 7075-T6, black anodized
- Protector: Clean Ring, anodized in red color
Steering
- Headset: Clean integrated Tapered 1 1 1/8" - 1.5", with 7075-T6 aluminum cups. Sealed bearings, red finish.
- Stem: Clean 155 mm x 25°, 31.8mm Oversized handlebar diameter, with two bolt clamp.
- Grips: Clean foam grips, black color.
- Handlebars: Clean 7075 Double Height 103 mm made of aluminum, 720 mm long, 31.8 mm Oversized diameter, matte black finish with Clean logos.
Geometry
(1) Wheelbase:Â 1070 mm (short) and 1090 mm (long)
-----------------------------------------------
(2) Rear End: 370 mm
-----------------------------------------------
(3) Bottom Bracket Height: +66 mm.
-----------------------------------------------
(4) Head Angle: 72°.
-----------------------------------------------
(6)Â Reach:Â 693 mm (short) y 713 mm (long)
-----------------------------------------------
Weight
- 9.260 Kg.
| FRONT BRAKE | HS |
| REAR BRAKE | HS |
