Available in 2 versions: with V-brake or Magura Mt2 Disc Brakes.
This product is no longer in stock
The new Clean S1 20” 920mm is the ideal bike for a smooth transition between kids and adults bikes! Its 920mm length works perfectly during growth years (120-140cm / 3.9-4.6ft), and it’s also built with hand-picked components with Clean’s quality guarantee and the best value for money!
Frame and fork
- Frame: Clean S1 20” 920mm, made from 6061-T6 aluminium alloy, with V-brake and IS Disc brake mounts, in white with black and red Clean graphics
- Forks: Clean S1 20” Cr-Moly, with V-brake and IS Disc brake mounts, in white with black and red Clean graphics
Wheels
- Front hub: Clean S1 100mm
- Rear hub: Clean S1 116mm
- Front rim: Clean 20”, single wall, 32mm wide, 32 spoke holes
- Rear rim: Clean 20”, single wall, 32mm wide, 32 spoke holes
- Spokes: Clean Stainless, black
- Front inner tube: Trial 20”
- Rear inner tube: Trial 20”
- Front tyre: Innova 20”
- Rear tyre: Innova 20”
Brakes
- Front brake: V-Brake
- Rear brake: V-Brake
- Brake pads: V-Brake
Drivetrain
- Cranks: Clean JIS 155mm
- Bottom bracket: Clean JIS, sealed bearings
- Freewheel: Clean 16T
- Chain: YBN, silver
- Rear sprocket: Clean 14T
- Pedals: Platform pedals
- Bashplate: Clean 2-piece bashplate
Steering
- Headset: Clean 1 1/8” external headset
- Stem: Clean 145mm x 25º
- Grips: Clean foam
- Handlebar: Clean S1 680mm long, 31.8mm Oversized handlebar diameter
Geometry:
- Wheelbase: 920mm
- Chainstay length: 350mm
- Bottom bracket rise: +40mm
- Head angle: 71º
Weight
- 8.86Kg
Additional information:
You can install a hydraulic rim brake on this bike by using the Magura Evo2 adaptors: http://bit.ly/MaguraEvo2 .
Some pictures may not match the item described, so please read the description carefully.
This bike is partially set up by our workshop, so the customer will only have to set both the front wheel and the headset up.
If you have any doubts, please contact to info@trial-bikes.com .
Watch the video below to see the key points of this new bike:
SIZE | 20" |
RIDER HEIGHT | 120cm-140cm |
FRONT BRAKE | Disc |
FRONT BRAKE | V-Brake |
REAR BRAKE | Disc |
REAR BRAKE | V-Brake |
