Breath Carbon Riser Bar

Description and materials
- New, high quality carbon handlebar from Breath, for 2014.
- Developed and tested for the last few months by the Breath Team Elite riders Gilles Coustellier and Zhao Xuan.
- Fully made from Carbon Fiber, now with several unidirectional layers instead of crossed layers.
- 730mm long, instead of the standard 720mm to achieve higher stability, which is essential in a high-BB bike.
- Its backsweep of 8.7º and upsweep of 12.1º make it really comfortable for all 20”, 24” and 26” bikes.
- Ø 31.8mm oversized clamp diameter, suitable for almost all trial stems.
- Textured sections at the bar clamp help keep the bars in place.
- Features central marks to fit the bar in the stem accurately.
- Two finishes available: both in matt black with red central marks, and Breath logos in white or white/black color.

Lengths
- Length: 730mm
- Upsweep: 12.1º
- Backsweep: 8.7º
- Total rise: 92.5mm

Finishes
- Matt black finish, with red central marks.
- Breath logos in white color or with white outlines and black interior.

Weight
- 230g
